Research on Strategies for Improving Output Voltage Accuracy and Error Compensation Methods for Grid Simulators

I. Introduction

Grid simulators are core testing equipment used to simulate grid characteristics such as voltage, frequency, and harmonics. They are widely applied in scenarios including grid-connection testing for new energy generation, R&D of power electronic equipment, and verification of aerospace power supply systems. With the power industry's rising requirements for equipment performance, the output voltage accuracy of grid simulators has become a key metric for evaluating their performance. High-precision output ensures the authenticity and reliability of test results for devices under test, while low-precision output may lead to product misjudgment or deviations in performance evaluation. This article will systematically analyze the core factors affecting the output voltage accuracy of grid simulators, elaborate on accuracy improvement strategies from three dimensions—hardware optimization, software compensation, and system calibration—and introduce the engineering implementation of typical error compensation methods.

II. Core Factors Affecting Output Voltage Accuracy of Grid Simulators

Grid simulators achieve power conversion through an AC-DC-AC topology, and their output voltage accuracy is constrained by multi-stage factors, mainly categorized into three types: hardware inherent errors, dynamic load errors, and environmental interference errors.

2.1 Hardware Inherent Errors

· Nonlinearity of Power Devices: The on-state voltage drop and switching delay of power switching devices such as IGBTs and MOSFETs exhibit discreteness, causing harmonic distortion in the output waveform. Especially under low-load conditions, nonlinear errors can account for more than 60% of the total error.

· Sampling Circuit Errors: Zero-point drift and gain deviation of voltage/current sampling chips, as well as the temperature coefficient of sampling resistors, directly affect the accuracy of feedback control.

· Transformer and Inductor Errors: The leakage inductance and magnetic core saturation characteristics of output isolation transformers, as well as the parasitic resistance of filter inductors, lead to voltage amplitude attenuation and phase shift.

2.2 Dynamic Load Errors
When the device under test is a nonlinear load (such as a rectifier or inverter) or an impact load, rapid changes in load current can cause output voltage fluctuations in the grid simulator:

· During sudden load changes, the charging and discharging delay of the output filter capacitor causes voltage sags or overshoots.

· Harmonic currents generated by nonlinear loads are injected into the grid simulator, interfering with the purity of its output waveform.

2.3 Environmental Interference Errors

· Temperature Drift: Changes in ambient temperature cause variations in the on-state voltage drop of power devices and the resistance of sampling resistors. In a wide temperature range of -40℃ to 60℃, temperature drift can reduce output voltage accuracy by 2–3 times.

· Electromagnetic Interference: Electromagnetic radiation in industrial environments can interfere with sampling and control signals, causing random fluctuations in output voltage.

III. Strategies for Improving Output Voltage Accuracy

3.1 Hardware Design Optimization

· Selection of High-Precision Power Devices: Choose third-generation semiconductor devices (such as SiC MOSFETs) with low on-state voltage drop and good switching consistency; their nonlinear errors are more than 40% lower than those of traditional IGBTs. Adopt modular design, strictly screen and match power units to ensure parameter consistency of devices.

· Sampling System Upgrade: Use high-precision ADC chips with 16 bits or more, paired with low-temperature-coefficient metal film resistors to form the sampling circuit, achieving a sampling accuracy of 0.05%. Add isolation amplifiers to sampling channels to avoid strong electrical interference affecting sampling signals.

· Optimization of Filtering and Isolation Topologies: Adopt multi-stage LC filter circuits combined with active filtering technology to suppress output harmonics. Use nanocrystalline core transformers with low leakage inductance and high permeability to reduce magnetic circuit nonlinear errors.

3.2 Software Control Strategy Optimization

· Real-Time Waveform Calibration: Add a waveform predistortion compensation module to the control program, which adjusts the amplitude and phase of drive signals in advance based on the nonlinear characteristics of power devices to cancel out inherent device errors.

· Load-Adaptive Adjustment: Dynamically adjust output filtering parameters and control bandwidth by monitoring load current changes in real time, quickly stabilizing the output voltage during sudden load changes.

· Digital Filtering Technology: Adopt multi-stage adaptive filtering algorithms to suppress electromagnetic interference noise in sampling signals while preserving the dynamic characteristics of voltage signals.

3.3 System-Level Calibration and Environmental Adaptation

· Full-Range Static Calibration: Perform full-range calibration of the grid simulator's output voltage before leaving the factory, establish the correspondence between voltage amplitude and control signals, store it in a calibration database, and call it for real-time compensation during operation.

· Temperature Closed-Loop Compensation: Arrange temperature sensors in power units and sampling circuits to monitor ambient temperature in real time, dynamically adjust control parameters based on the temperature-error model to cancel out temperature drift effects.

· Electromagnetic Compatibility Design: Adopt measures such as shielded cabinets, grounding isolation, and signal filtering to meet the IEC 61000-4 electromagnetic compatibility standard and reduce the impact of external electromagnetic interference on output accuracy.

IV. Engineering Implementation of Typical Error Compensation Methods

4.1 Static Error Compensation
For zero-point drift and gain deviation in the sampling system, the "two-point calibration method" is used: at the 0% and 100% output voltage range points, collect the actual output voltage and sampling values respectively, calculate the zero-point compensation value and gain compensation coefficient, and perform real-time correction of sampling signals during operation. A certain model of grid simulator reduced static voltage error from 0.3% to 0.05% using this method.

4.2 Dynamic Error Compensation
For dynamic errors caused by nonlinear loads, "load current feedforward compensation" is adopted: collect load current signals in real time, adjust the drive signals of power devices in advance based on load characteristics to cancel out the impact of load current on output voltage. When testing rectifier loads, this method can reduce dynamic output voltage error from ±2% to within ±0.5%.

4.3 Temperature Drift Compensation
Establish a temperature-error model for power devices and sampling circuits, collect temperature data in real time using NTC thermistors arranged at key components, calculate compensation values based on the model in the control program, and adjust output voltage control parameters. In an environment of -40℃ to 60℃, temperature drift compensation can maintain output voltage accuracy within 0.1%.

V. Application Effects and Industry Verification

A new energy testing agency upgraded its 100kVA grid simulator using the above accuracy improvement strategies and compensation methods, achieving the following results:

· Output voltage accuracy improved from 0.2% to 0.05%;

· Voltage total harmonic distortion (THD) under nonlinear loads reduced from 1% to 0.2%;

· Accuracy stability in wide-temperature environments improved by 3 times, meeting testing requirements for extreme environments such as plateaus and polar regions.

The equipment has been successfully applied to grid-connection testing of photovoltaic inverters and energy storage converters, with a deviation of less than 0.1% between test results and actual operating data from the State Grid, verifying the effectiveness of the accuracy improvement solution.

VI. Summary and Outlook

In fields such as new energy grid connection and power electronic equipment testing, the output voltage accuracy of grid simulators directly relates to the reliability of test results and the feasibility of technological innovation. This accuracy improvement is never a breakthrough in a single link, but a systematic outcome of deep collaboration between hardware optimization, software compensation, and system calibration—only by targetedly tackling the three core pain points of hardware inherent errors, dynamic load fluctuation errors, and environmental interference errors can high-precision, high-stability voltage output be achieved, laying a solid foundation for industry testing.
